RKC RD400 Temperature Controller
Digital Temperature controllers RD100 / RD400 / RD500 / RD700 / RD900
Brand : RKC
Category : Temperature Controllers
SKU : RD series（RD100 / RD400 / RD500 / RD700 / RD900)
Number of input: 1 point
Input type: ※See the Input Range Code for the input range.
Group 1: Thermocouple K, J, T, S, R, E, B, N, W5Re/W26Re, U, L, PLII
Group 2: RTD Pt100,JPt100
Sampling time: 0.25 sec.
Measurement accuracy：±(0.2% of displayed value+1 digit) ※Depends on the input and the range.
Alarm function (max.4 points): Temperature alarm, Heater break alarm, Loop break alarm, FAIL
CT input for Heater Break Alarm : Max. 2 points
Analog retransmission output: Output type is the same as OUT1 ※The signal is produced from OUT2 terminal.
Digital input: Max.2 points
Communication interface: RS-485
Input type: ※See the Input Range Code for the input range.
Group 1: Thermocouple K, J, T, S, R, E, B, N, W5Re/W26Re, U, L, PLII
Group 2: RTD Pt100,JPt100
Sampling time: 0.25 sec.
Measurement accuracy：±(0.2% of displayed value+1 digit) ※Depends on the input and the range.
Alarm function (max.4 points): Temperature alarm, Heater break alarm, Loop break alarm, FAIL
CT input for Heater Break Alarm : Max. 2 points
Analog retransmission output: Output type is the same as OUT1 ※The signal is produced from OUT2 terminal.
Digital input: Max.2 points
Communication interface: RS-485
