IC693MDL753 GE Fanuc Series 90-30 Discrete Output Module

The 12/24 volt DC, 0.5A Positive Logic Output module for the Series 90-30 Programmable
Logic Controller provides 32 discrete outputs. The outputs are arranged in four isolated groups
of eight (A1 – A8, B1 – B8, C1 – C8, and D1 – D8); each group has its own common. The
outputs are positive logic or sourcing type outputs in that they switch the loads on the positive
side of the power supply, and therefore supply current to the load.
